Making In Process 3D Measurement a Reality [High-speed 2D/3D Laser Scanner LJ-V7000 Series] Download measurement guide

Using the LJ-V7000 Series
for 2D measurements

74 types of measurement modes enable a wide variety of inspections.

  • HEIGHT

    Measures the height within the specified range.

  • WIDTH AND POSITION

    Measures the width and positions under the specified conditions.

  • HEIGHT DIFFERENCE

    Measures the height difference from a reference point to a measurement point.

  • CROSS SECTIONAL AREA

    Measures the cross sectional area from a reference surface.

  • ANGLE AND INTERSECTION

    Measures the angle between and the intersection point of a pair of detected straight lines.

  • MASTER PROFILE COMPARISON

    Makes a comparison with the registered master shape and then measures the area with the largest difference in height.

  • DISTANCE
    (POINT - POINT)

    Measures the height within the specified range.

  • RADIUS AND MIDPOINT

    Measures the width and positions under the specified conditions.

  • THICKNESS

    Measures the thickness within the specified range.

  • SIMPLE 3D SETTINGS (HEIGHT)

  • SIMPLE 3D SETTINGS (HEIGHT DIFFERENCE)

  • SIMPLE 3D SETTINGS (POSITION)

RECOMMENDED ITEMS

LJ-V Series Ultra-High Speed In-line Profilometer Catalogue (English)

LJ-V Series Ultra-High Speed In-line Profilometer Catalogue (English)
  • [File type]PDF:3.48MB
