Wide-Area 3D Microscope
Quick and accurate profile measurements

What is the Wide-Area 3D Microscope?
It is a non-contact 3D measurement system that is able to measure wide areas quickly and accurately. It’s perfect for measuring profile, roughness, flatness, wear volume, or comparing 3D scan data to CAD files and determining if a part is good or bad.
Why the Wide-Area 3D Microscope?
Conventional 3D measurement tools have limited viewing areas and require significant time and effort to properly measure a surface. With the VR-5000, the user places their sample on the stage, clicks measure, and receives 3D measurements in seconds, even on complex surfaces and wide areas. Fast, easy, and simple.

How does the Wide-Area 3D Microscope work?
It emits structured light through several double-telecentric lenses to reduce distortion and receive the most accurate data possible. Distortions in the light bands caused by height differences are converted to height using triangulation. The high-accuracy CMOS sensor also allows for a full color imaging.

3D Measurements in
Seconds
Multiple Telecentric
Lenses for High
Accuracy
Accurate 3D
Measurements on
Complex Surfaces
Waviness and Warpage
Easy-to-use Analyzer
Software

SAME DAY SHIPPING DIRECT SUPPORT DIRECT SALES

KEYENCE has been an industry leader in sensing technology since 1974. KEYENCE's direct sales team visits customers with live demo equipment to find the best possible solution for all applications.
